CA3-Series
CVD Coated Carbide for Cast Iron
Download Brochure Locate DistributorGray & Nodular Cast Iron Machining with CA3
3 powerful new turning grades and chipbreakers
to tackle multiple cast iron turning applications
High Coating Adhesion Results in Stable Machining
Strong Intra-coating Adhesion
With a micro intra-coating structure higher adhesion is possible by increasing the bonding surface with aluminum oxide layer.
The impact-resistant intra-coating structure interface strength is increased by 20% (compared to our other products), which resists boundary destruction.
Cutting Conditions : Vc = 490sfm, D.O.C. = 0.059", f = 0.012ipr, Wet, CNMG432 type, Facing, (After withstanding 3,000 Impacts), Workpiece: 100-70-03 (8 Grooves in Workpiece)
Micro TiCN Coating Provides Excellent Wear Resistance
Unique Insert Grades For Various Cast Iron Machining Applications
CA3-Series Grades
3 Grades for Various Cast Iron Machining Applications
CA310 Gray Cast Iron (1st Recommendation)
Grade for high-speed continuous machining and improved tool life through the deposition of a thickened alumina coating layer.
For finishing to roughing of gray cast iron.
Cutting Conditions : Vc = 980sfm, D.O.C. = 0.059", f = 0.012ipr, Wet, CNMG432 type, Workpiece: 100-70-03
CA315 Nodular Cast Iron (1st Recommendation)
For continuous to interrupted machining with a good balance of wear resistance and stability.
Excellent performance for machining gray and nodular cast iron by optimizing the total coating layer thickness.
High efficiency and long tool life.
Cutting Conditions : Vc = 660sfm, D.O.C. = 0.059", f = 0.018ipr, Wet, CNMG432 type, Workpiece: 100-70-03 (8 Grooves in Workpiece), Interruption Evaluation: 2 Times
CA320 Interrupted Machining
Improved stability with CVD layer structure with high adhesion.
Long tool life for nodular cast iron during heavily interrupted or high-speed machining.
Cutting Conditions : Vc = 490sfm, D.O.C. = 0.059", f = 0.012ipr, Wet, CNMG432 type, Workpiece: 100-70-03 (8 Grooves in Workpiece), Interruption Evaluation: 2 Times
